Ultra96™ is an Arm-based, Xilinx Zynq UltraScale+™ MPSoC development board based on the Linaro 96Boards specification. The 96Boards’ specifications are open and define a standard board layout for development platforms that can be used by software application, hardware device, kernel, and other system software developers. Ultra96 represents a unique position in the 96Boards community with a wide range of potential peripherals and acceleration engines in the programmable logic that is not available from other offerings.
Features
• Xilinx Zynq UltraScale+ MPSoC ZU3EG A484
• Micron 2 GB (512M x32) LPDDR4 Memory
• Delkin 16 GB microSD card + adapter
• Pre-loaded with PetaLinux environment
• Wi-Fi / Bluetooth
• Mini DisplayPort (MiniDP or mDP)
• 1x USB 3.0 Type Micro-B upstream port
• 2x USB 3.0, 1x USB 2.0 Type A downstream ports
• 40-pin 96Boards Low-speed expansion header
• 60-pin 96Boards High-speed expansion header
• 85 x 54mm form factor
• Linaro 96Boards Consumer Edition compatible
