The new AC/DC product series TAD30-P, TAD65-P, and TAD125 can provide high peak power to meet needs of temporary high load situations in industrial and communication applications, such as electric tools, electric beds/chairs, printers, and other electric motors equipment.
The new series provide a flexible combination of electrical and thermal performance, that provide up to 10 seconds, 1.3 times the peak load tolerance, and supports operation in a natural air-cooled environment. This can effectively reduce costs due to not being necessary to select a higher output power module to cover short term peak power requirements
The operating temperature range of the series is -40 to +85 °C, and has high efficiencies of up to 92%. This high efficiency means higher reliability and reduced system heat dissipation requirements.
A useful feature is that the voltage output is adjustable, up to +/- 10%.
These series have low standby power consumption, a complete programme of protection functions, 3000VAC reinforced isolation, and can operate at altitude of up to 5000 metres.
The TAD125 and TAD65-P series are available in 4 formats, open frame, U-Chassis, Fully enclosed and a din rail format. The TAD30-P are open frame. All models are certificated by IEC/ EN/ UL 62368-1.
Highlights & Features
■ 130% peak power
■ low standby power consumption
■ Wide input voltage range 85 to 264VAC, 47 to 63Hz
■ Built-in EN 55032 EMI Class B filter
■ Output voltage adjustable
■ 3000 VAC input to output reinforced insulation
■ Protection type Class I and Class II
■ Low leakage current under 75µA
■ Operating altitude up to 5000m
■ 3-Year warranty
■ IEC/ UL/ EN 62368-1 safety approval
Our product specialists are on hand to assist with product selection and guide you through the design cycle. We can offer technical and commercial support and arrange for samples. Datasheets are downloadable from the Luso website.
