Signal Transformer Announces Wireless Charging Coils in Both Single and Multiple Windings for General and Automotive Applications


Signal Transformer, a Bel group company (NASDAQ: BELFA and BELFB) and global manufacturer of custom and standard transformers, chassis and high frequency chokes and inductors, SMD inductors and wireless charging coils, announce their new Wireless Charging Transmission Coils (WCC) in both Single and Multiple Windings for smart car applications, consumer products, controllers, wearable devices, robotic cleaners and drones.

Signal’s WCC’s feature pin cooling technology and tight pin tolerance control within +/-1.0 mm after the Tin Immersion process. They come in two core shapes, square/rectangular (Q) or circular (c), and feature Qi standard compliance and customizable size and shape characteristics, with a low profile and high mechanical intensity. Inductance tolerance is ± 5% for (J) and ± 10% for (K) with inductance of 6R3 for 6.3uH, and an operating temperature of -20°C to 85°C for general applications and -40°C to 125°C for automotive. Signal’s WCC’s comply with all environmental requirements, including RoHS, REACH, Prop 65 and Conflict Minerals.

Signal’s WCC Series utilizes inductive coupling to transfer signals, data and power from one source to another. Of its many applications, the most common are base chargers for cell phones, tablets, toothbrushes, remotes and similar devices. The WCC’s use of inductive coupling eliminates conductive connections and traditional wiring, seamlessly transferring data and power while avoiding the mechanical abrasion, corrosion and wearing-out of conductive contacts. The fixed-in position inductive coils are non-moving, resistant to vibration and corrosion and are designed for reliability and longevity.

The Wireless Charging Coils will be available for prototype and production quantities through our distribution network via Digi-Key and Mouser. For more detailed information, visit belfuse.com/signal or download the datasheet: Single Windings or Multiple Windings. For technical inquiries, call Signal at 866-239-5777, visit belfuse.com/signal or email sales@signaltransformer.com.
